| Built By: | Varley Marine (Hamble) |
| Build Group: | XP |
| Fate: | Scrapped 1945 |
Unofficially named Piker
Submariner who helped to mortally damage Tirpitz and spent six months in solitary confinement.
| 01-09-1941 | Laid Down |
| 15-03-1942 | Launched |
| 20-03-1942 | Completed |
| 04-11-1942 | Submarine X-3 sank in a training accident in Loch Striven due to a leaking engine valve. The Submarine was raised later the same day by the Salvage Vessel HMS Tedworth. There were no casualties, all three Officers onboard (all Sub Lieutenants) were Trainees and managed to escape safely using DSEA sets after about 40 minutes on the bottom in approximately 110 feet of water. One (Sub Lieutenant John Thornton Lorimer RNVR) continued to serve in X-Craft but the other two, Sub Lieutenants Gay and Laites, transferred to another Branch of the Navy. After refitting at Vickers at Barrow in Furness the Submarine was returned to service. |
|
||
| Official | ||
| Admiralty Approved | 22nd Nov, 1955 | |
| Symbology | These manned craft strike from under the water. | |
| Design Notes | In chief, wavy white overall, two tilting spears in saltire proper, each grasped by a gold gauntlet. | |
| Additional Notes | This is a 'Type' badge assigned to all X-Craft. | |
| Length overall | 43 ft |
| Beam | 8 ft (with charges) / 5 ft 6 inch (without charges) |
| Displacement | With Charges: 30 tons (surface) / 32 1/2 tons (submerged) |
| With Charges: 32 1/2 tons (submerged) | |
| Without Charges: 27 tons (surface) | |
| Without Charges: 29 1/2 tons (submerged) | |
| Diving Depth | 200 ft |
| Speed | With Charges: 6.5 knots (surface) |
| 5 knots (submerged) | |
| No. of shafts | 1 |
| Armament | 2 x 2-ton side charges |
| Limpet mines | |
| Endurance | Surface: 1100 miles at 4.5 knots (with charges) |
| Surface: 1400 miles at 4.5 knots (without charges) | |
| Submerged: 85 miles at 2 knots (with charges) | |
| Submerged: 85 miles at 2 knots (without charges) | |
| Complement | 3 |
