| Built By: | Scotts (Clyde) |
| Build Group: | Sword |
| Fate: | Scrapped in July 1922. |
| 1916: | Commander | Geoffrey Layton |
An experimental submarine built in the hope of achieving a speed of 20 knots by using the steam turbine rejected from HMS Nautilus.
This submarine was developed from a design prepared for the Royal Navy by the Italian submarine designer Cesare Laurenti, whose designs were at that time in use by several navies.
HMS Swordfish was renamed HMS S1 on 1 April 1916. Captained by Commander Geoffrey Layton, she was treated as an experimental vessel and regarded as impossible to make into an effective warship, but much was learned about the operation of steam submarines, making possible the subsequent design of the steam-powered K class.
Between 27 June 1917 and 24 January 1918 was converted to a surface patrol vessel, reverting back to being named HMS Swordfish in July 1917.
Chapter 5 - Double-Hull Submarines
The Development of HM Submarines from Holland 1 (1901) to Porpoise (1930)
Chapter 7: Double-Hull Overseas Types - Nautilus, Swordfish (1913), G & J Classes
The Development of HM Submarines from Holland 1 (1901) to Porpoise (1930)
| 28-02-1914 | Laid Down |
| 18-03-1916 | Launched |
| 21-07-1916 | Completed |
| Length overall | 231 ft 6 inch |
| Beam | 23 ft |
| Depth | 16 ft 9 inch |
| Displacement | 932 tons (surface) |
| 1470 tons (submerged) | |
| Speed | 18 knots (surface) |
| 10 knots (submerged) | |
| Propulsion | 2-shaft steam turbine, 2 electric motors, 3750shp/1400shp |
| Endurance | 3,000 nautical miles at 8.5 knots |
| Armament | 2 x 12pdr guns |
| 2 x 21 inch torpedo tubes (bow) + 2 torpedoes | |
| 4 x 18 inch torpedo tubes (beam) + 8 torpedoes | |
| Oerlikon cannon | |
| 3 x 0.303 inch machine-guns | |
| Complement | 18 |
| Class: | 1944 - 1952: XE Class |
| Built By: | Broadbent (Huddersfield) |
| Build Group: | XE |
| Fate: | |
| Scrapped Australia 1945/46 | |
