| Built By: | Cammell Laird (Mersey) |
| Build Group: | L1 |
| Fate: | Scrapped October 1930 |
| 1918: | Lieutenant | Thomas Kerr | |
| 1925: | Lieutenant Commander | Henry Berwick Crane |
1923 - Reserve Flotilla. Hong Kong.
| Length overall | 231 ft 1 inch |
| Beam | 23 ft 6 inch |
| Draught | 13 ft 3 inch |
| Displacement | 891 tons (surface) |
| 1074 tons (submerged) | |
| Diving Depth | 150 ft |
| Speed | Surface 17 knots (design) |
| Surface 17 to 17.5 knots (service) | |
| Submerged 10.5 knots (design) | |
| Submerged 10.5+ knots (service) | |
| No. of shafts | 2 |
| Propeller | 3 blades, 5 ft 7 inch diameter |
| Endurance | Surface: 2800 miles at full power (design) |
| Surface: 2850 miles at full power or 3600 miles at half full power (service) | |
| Submerged: 14 miles at full power (design) | |
| Submerged: 14 miles at full power or 65 miles at 5 knots (service) | |
| Armament | 4 x 18 inch bow tubes |
| 2 x 18 inch beam tubes | |
| (10 torpedoes carried) | |
| 1 x 4 inch gun | |
| Complement | 3 Officers and 33 Ratings |
