| Built By: | Vickers (Barrow) |
| Build Group: | XT |
Unofficially named Extended.
Less elaborately equipped as previous boats as they were intended for training.
| Length overall | 51 ft 7 inch |
| Beam | 8 ft 6 inch (with charges) |
| 5 ft 9 1/2 inch (without charges) | |
| Displacement | Without Charges: 27 tons (surface) |
| Without Charges: 29 1/2 tons (submerged) | |
| Diving Depth | 300 ft |
| Speed | With Charges: 6.5 knots (surface) |
| With Charges:5 knots (submerged) | |
| No. of shafts | 1 |
| Armament | 2 x 2-ton side charges |
| Limpet mines | |
| Endurance | Surface: 1320 miles at 4 knots (with charges) |
| Surface: 1860 miles at 4 knots (without charges) | |
| Submerged: 80 miles at 2 knots (with charges) | |
| Complement | 4 |
L 16 |
|
| Class: | 1916 - 1945: L Class |
| Built By: | |
| Build Group: | L2 |
|
Fate: Sold 16th February 1932 |
|
